舒适
-有序的空间、协调的动作，人体工程设计改善了患者和医生在牙科椅上每一分钟的体验
科技
-集成新一代设备、器械、控制和应用，以及LED显示控制面板，高效完成口腔治疗工作
全面
-出色的性能与美感，个性化配件和丰富的功能体验，满足针对不同患者的多种治疗需求
安全
-全水路管道消毒，有效消除水中微生物，快速去除细菌生物膜
细节展示:
全自动一键消毒系统
全水路管道消毒
-26分钟水路管道快速消毒
消除水中微生物
-杀死管内浮游细菌
消除细菌生物膜
-冲走管壁的生物膜
全管路消毒示意
技术可靠
-有效消除水路管道的有害细菌
效率高效
-规定时间内进行数次消毒循环
安全便捷
-消毒完成后可设置自动关机
消毒步骤及方法
.jpg)
Ⅰ陶瓷痰盂安装消毒配件
.jpg)
Ⅱ手机、三用枪、洁牙机等插入消毒配件专用位置
.jpg)
Ⅲ按照标准稀释消毒液
.jpg)
Ⅳ加入消毒水
.jpg)
Ⅴ打开工具盘手机水调节阀
.jpg)
Ⅵ按下一键消毒开关
数控系统
Barometer
-It is convenient for doctors to observe the air pressure of handpiece at any time
LCD status display
-It is convenient for doctors to observe the working status of the dental chair at any time
Function control area
-15 function buttons, 9 memories, comprehensive function
Fault self-check function
It can check the working status of the operating light, water supply, flushing water, heater and viewer. It will display blue normally, and the icon will turn red when there is an abnormality. If the PCB, control box, main control key board, etc. have abnormal communication, the upper right corner will display red, which means the connection fails, which is convenient for troubleshooting.
Disinfection function
It displays the disinfection status and the time required, so that the doctor can understand the disinfection process more clearly, and automatically turns off the machine after disinfection is completed, which is safe and worry-free.
The 4th generation of dental chair compensation design
·It fits the curve of the back of the human body and provides patients with peace of mind and comfortable support. The dental chair can be adjusted to a wider range of height angles to ensure that doctors of all sizes can find a more comfortable working position. This provides a better viewing and treatment angle for the physician and allows the patient to lie down and get up from the dental chair.
·It has a synchronized compensation function to reduce the patient's body angle change when the dental chair is tilted.
Maximum seat position:<700mm
Minimum seat position:>400mm
Smooth lift and no lag
Fixed anti-slip setting
The headrest position can be adjusted by pressing to prevent the headrest from sliding unsteadily, ensuring the stability of the headrest and making treatment safer.
The dental chair is made of high-density memory foam
Memory foam has good elasticity, moderate softness and slow rebound; it disperses the pressure on the contact surface between the dental chair and the human body, so that the patient's body can naturally stretch and relax.
Environmental micro-fiber leather
Environmental micro-fiber leather has a delicate touch, smooth and tight skin, uniform thickness and bright colors; it has good abrasion resistance.
Armrest
The armrest provide a better grip point, making it easier for the patient to lie up and down the chair.
Easy-to-clean foot pad
A high-density plastic foot pad makes it easy to clean the dirt left on the foot pad, avoiding the impact on the leather cushion when wiping, and prolonging the service life of the dental chair.
The top sensor switch realizes the integration of manual and induction
-Two-colour light source specifically for dentistry
White light
-4 white light emitting diodes (LED)
Yellow light
-4 white light emitting diodes (with filter)
Anye's manual, induction integrated dental light has a large projection angle and the light spot conforms to the rectangular light spot required for oral surgery. High illumination 8000~30000 adjustable, colour temperature (5000k±10%)
.jpg)
Cast aluminium dental light arm
The cast aluminium dental arm has been tested 100,000 times for fatigue resistance and has a longer service life; it has improved mobility and is more flexible in multiple directions
Environmental micro-fiber leather
Ⅰ- Flexible movement of the lamp head, whether sitting or standing, to meet a variety of clinical needs
Ⅱ- Extra long arm for optimal illumination of all types of clinical
Ⅲ - The lamp head is designed to move in three axes for easy positioning
Ⅳ - Mounting mode: Integrated mounting on the equipment
The design box of the door type can be rotated 45°, which is convenient for daily maintenance; the rotating side box creates space for the assistant to operate, making it easy for the doctor and assistant to operate with four hands.
ASA casting process
Selected high quality ASA casting material, one-piece casting process; high purity, using 100% pure ASA material for production
Cast aluminium cabinet
Standardized production, one-piece precision casting molding super-strength cast aluminum cabinet, tough and durable, no deformation, long-term use without rust. Light weight, small force on the side box, strong stability of the dental chair, independent layout of water, electricity and gas, clear structure, convenient for subsequent maintenance
The down mounted instrument tray has a unique design and appearance. The whole is made of cast material, and 100% pure ASA material is integrally formed.
Keypress function of water, air, electric switch
The lower left corner of the instrument tray is equipped with a key to turn off the main switch of water, gas and electricity. It is easy to press, convenient and simple to get off work.
Instrument tray silicone pad
Anti-slip silicone pad design protects the surface of the instrument tray, facilitates postoperative cleaning and maintains hygiene.
The assistant tool tray is a cast plastic shell with a beautiful appearance, which allows the assistant to assist the doctor in four-handed operation, improving the efficiency and precision of the treatment
Assistant tool tray
Ⅰ7 button control panel
It is convenient for assistant to control the common functions of dental chair up and down, water heating, phlegm flushing and mouthwash .
ⅡTool tray silicone pad
The tool tray can be used by the assistant to place small instruments. The silicone pad prevents the instruments from slipping and is easy to clean, keeping the tool tray hygienic.
Removable spittoon for easy cleaning and sterilization after use. 180° rotating design easy for patients to spit. The drainage is smooth, the water speed is ≥4.5L/min, and the disinfection cycle is efficiently promoted.
Tissue box
The side box comes with a tissue box, no additional installation is required. The tissue box is located next to the left armrest, convenient for patients to take out and wipe after spitting.
.jpg)
.jpg)
Backrest can be tilted forward and backward
Cushion can be tilted forward and backward horizontally
-Environmental micro-fiber leather
-Five-star chair frame
-High-density memory foam
It is ergonomically designed to fit the curve of the lumbar spine and relieve the pressure on the waist caused by prolonged sitting. Bionic curved design to support the waist and protect the neck, effectively reducing occupational strain on dentists
-6-way adjustment to maintain the center of the body
-Support the doctor's waist and maintain a soft and comfortable touch
-Recessed seat cushion wraps around the hip and leg area
.jpg)
Chair can be raised and lowered
Cast aluminium frame
Lightweight and flexible cast aluminium frame; resistant to oxidation and rust, long service life
Universal silent pulley
It is a low foot position control that keeps the pedal parallel when stepping on it to protect the ankle. Cast aluminum pedal bottom plate, lightweight and not easy to slide, strong stability and high durability.
It incorporates chair with self-lock function, chair position control, sputum flushing, mouthwash, reset and dental light control
技术参数:
| 电源电压 | 220V-50HZ/60HZ |
| 电机电压 | 24V |
| 气压 | 0.5MPa-0.8MPa |
| 水压 | 0.2MPa-0.4MPa |
LED 灯:
| 额定输入电压 | AC12V±10% |
| 最大功率 | 15VA |
| 光源 | 1 发光二极管 (LED) |
| 色温 | 5,000K ± 10% |
| 照度 | 可调节从 8,000 到 30,000 |
配置:
| 24V直流电动椅 |
| 移动器械盘 |
| 三用枪（助手架）冷水/热水 |
| 副手操作控制系统 |
| 漱口水加热系统 |
| 强吸唾器 |
| 弱吸唾器 |
| 安全急停开关 |
| 冲痰供水定量给水设置系统 |
| 可拆卸90度移动痰盂盆 |
| 机椅互锁 |
| 多功能脚踏开关 |
| 一键吐痰位 |
| 水、电、气总开关 |
| 4孔LED口腔灯 |
| 九个记忆椅位 |
| 豪华医生座椅C型 |
| 搁物玻璃托盘 |
| 可180°旋转侧箱 |
| 玻璃痰盂 |
| 机椅联动补偿椅位 |
| 第三代补偿联动椅架 |
| 豪华超细纤维环保皮 |
| 水单向阀(防回流功能） |
Careful quality, attention to detail
Emergency safety Switch
Screw-in filter
Four generation synchronized comfort large chair frame
Storage plate
Imported tube
Built-in junction box
